Blackmagic TERANEX Mini

SDI to HDMI 12G

Connections

• SDI Video Inputs: 1 x 12G-SDI SD/HD/2K/4K auto switching.
• SDI Video Outputs: 1 x 12G-SDI loop output.
• HDMI Video Outputs: 1 x HDMI 2.0 type A connector with support for 2160p60.
• Analog Audio Outputs: 2 channels professional balanced analog audio via XLR connectors. Right XLR can be configured for Timecode output.
• Digital Audio Outputs: 4 channels professional 110Ω balanced digital audio via XLR connectors. Right XLR can be configured for Timecode output.
• Embedded Audio Support: 8 channels.
• Multi Rate Support: 270MB, 1.5G, 3G, 6G and 12G.
• Updates and Configuration: USB or Ethernet.

Reclocking: Yes

SDI Input Standards

• SD Video Standards: 525i59.94 NTSC, 625i50 PAL
• HD Video Standards
  720p50, 720p59.94, 720p60
  1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
  1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30
  1080i50, 1080i59.94, 1080i60
• 2K Video Standards
  2K DCI 23.98p, 2K DCI 24p, 2K DCI 25p
  2K DCI 23.98PsF, 2K DCI 24PsF, 2K DCI 25PsF
• Ultra HD Video Standards
  2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60
• 4K Video Standards
  4K DCI 23.98p, 4K DCI 24p, 4K DCI 25p
• SDI Compliance
  SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 424M, SMPTE 425M Level A and B, SMPTE 2081-1, SMPTE 2081-10, SMPTE 2082-1 and SMPTE 2082-10
• SDI Video Rates
  SDI video connections are switchable between standard definition, high definition level A and level B 3G-SDI, 6G-SDI and 12G-SDI.
• SDI Video Sampling
  4:2:2 and 4:4:4
• SDI Audio Sampling
  Television standard sample rate of 48 kHz and 24-bit.
• SDI Color Precision: 4:2:2 and 4:4:4
• SDI Color Space: YUV and RGB. 33 point LUTs can be loaded via Teranex Utility.

HDMI Output Standards

• SD Video Standards: 525i59.94 NTSC, 625i50 PAL
• HD Video Standards
  720p50, 720p59.94, 720p60
  1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
  1080i50, 1080i59.94, 1080i60
• Ultra HD Video Standards
  2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60
• 4K Video Standards
  4K DCI 23.98p, 4K DCI 24p, 4K DCI 25p, 4K DCI 29.97p, 4K DCI 30p
• HDMI Color Space: REC 601, REC 709
• HDMI Color Precision: YUV 4:2:2 and RGB 4:4:4 in HD, 2K and 4K.

Software

• Software Control: Mac™ and Windows™ software upgrade via USB or Ethernet.
• Internal Software Upgrade: Via included updater application.

Operating Systems

• Mac icon
• Mac 10.14 Mojave,
• Mac 10.15 Catalina or later.
• Windows Icon
• Windows 8.1 and 10.

Settings Control

• Basic Settings Control: Mini Switches, USB and Ethernet via free software utility.
• Optional Front Panel Control: Front mounted Smart Panel with LCD, rotary knob and six settings buttons.

Power Requirements

• Power Supply: 1 x built in international AC power supply with IEC C14 inlet. IEC Power cable required. 90 – 240V AC Input.
• Power Over Ethernet: Can be powered via 48V DC using PoE+ (power over ethernet).
• Power Consumption: 16 Watts
• Operational Voltage Range: 90 – 240V AC
